IFMC直角殼型銑刀

series

IFMC直角殼型銑刀

MODEL NO.	TYPE	D	D1	d1	L	A	ap max.	TEETH	INSERT
5154-240-022-07	IFMC90-50-22-AP10	50	40	22	40	10.4	10	7	AP..1003
5154-240-023-09	IFMC90-63-22-AP10	63	48	22	40	10.4	10	9	AP..1003
5154-240-034-11	IFMC90-80-27-AP10	80	62	27	50	12.4	10	11	AP..1003
5154-240-045-13	IFMC90-100-32-AP10	100	78	32	50	14.4	10	13	AP..1003
5154-240-056-16	IFMC90-125-40-AP10	125	89	40	63	16.4	10	16	AP..1003
5154-240-122-07	IFMC90-50-25.4-AP10	50	45	25.4	40	9.5	10	7	AP..1003
5154-240-123-09	IFMC90-63-25.4-AP10	63	50	25.4	40	9.5	10	9	AP..1003
5154-240-134-11	IFMC90-80-31.75-AP10	80	62	31.75	50	12.7	10	11	AP..1003
5154-240-135-13	IFMC90-100-31.75-AP10	100	78	31.75	50	12.7	10	13	AP..1003
5154-240-146-16	IFMC90-125-38.1-AP10	125	80	38.1	63	15.9	10	16	AP..1003
5154-242-022-05	IFMC90-50-22	50	45	22	40	10.4	16	5	AP..1604
5154-242-023-05	IFMC90-63-22	63	48	22	40	10.4	16	5	AP..1604
5154-242-034-06	IFMC90-80-27	80	62	27	50	12.4	16	6	AP..1604
5154-242-045-07	IFMC90-100-32	100	78	32	50	14.4	16	7	AP..1604
5154-242-056-08	IFMC90-125-40	125	89	40	63	16.4	16	8	AP..1604
5154-242-122-05	IFMC90-50-25.4	50	48.5	25.4	40	9.5	16	5	AP..1604
5154-242-123-05	IFMC90-63-25.4	63	50	25.4	40	9.5	16	5	AP..1604
5154-242-134-06	IFMC90-80-31.75	80	62	31.75	50	12.7	16	6	AP..1604
5154-242-135-07	IFMC90-100-31.75	100	78	31.75	50	12.7	16	7	AP..1604
5154-242-146-08	IFMC90-125-38.1	125	80	38.1	63	15.9	16	8	AP..1604

零配件：

INSERT	INSERT SCREW	WRENCH
AP..1003	M2.5-6.45-3.7-60	T8
AP..1604	M4-10-5.7-60	T15

SIFM熱膨脹直角殼型銑刀

MODEL NO.	TYPE	D	D1	d1	L	A	ap max.	TEETH	INSERT
5154-630-022-05	SIFM90-50-22	50	45	22	40	10.4	16	5	AP..1604
5154-630-023-05	SIFM90-63-22	63	48	22	40	10.4	16	5	AP..1604
5154-630-034-06	SIFM90-80-27	80	62	27	50	12.4	16	6	AP..1604
5154-630-045-07	SIFM90-100-32	100	78	32	50	14.4	16	7	AP..1604
5154-630-056-08	SIFM90-125-40	125	89	40	63	16.4	16	8	AP..1604
5154-630-122-05	SIFM90-50-25.4	50	48.5	25.4	40	9.5	16	5	AP..1604
5154-630-123-05	SIFM90-63-25.4	63	50	25.4	40	9.5	16	5	AP..1604
5154-630-134-06	SIFM90-80-31.75	80	62	31.75	50	12.7	16	6	AP..1604
5154-630-135-07	SIFM90-100-31.75	100	78	31.75	50	12.7	16	7	AP..1604
5154-630-146-08	SIFM90-125-38.1	125	80	38.1	63	15.9	16	8	AP..1604

零配件：

INSERT	INSERT SCREW	WRENCH
AP..1604	M4-10-5.7-60	T15
