SAF可調式刀桿

series

BT/SAF可調式刀桿 (SFC)

proimages/Products/Tool_holders/SAF/BT-SAF-SFC-4.5_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	d2	COMBINATION		WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	d2	BODY	FLANGE ADAPTER	WEIGHT (KGS)
5010-S27-006-110	BT30xSAF6C-110	158.4	110	52	6	21	BT30 x SAF25	SFC6 - 70	1.13
5010-S27-008-110	BT30xSAF8C-110	158.4	110	52	8	21	BT30 x SAF25	SFC8 - 70	1.12
5010-S27-010-110	BT30xSAF10C-110	158.4	110	52	10	24	BT30 x SAF25	SFC10 - 70	1.17
5010-S27-012-110	BT30xSAF12C-110	158.4	110	52	12	24	BT30 x SAF25	SFC12 - 70	1.15
5010-S27-016-115	BT30xSAF16C-115	163.4	115	57	16	27	BT30 x SAF25	SFC16 - 75	1.20
5011-S27-006-120	BT40xSAF6C-120	185.4	120	52	6	21	BT40 x SAF25	SFC6 - 70	1.86
5011-S27-008-120	BT40xSAF8C-120	185.4	120	52	8	21	BT40 x SAF25	SFC8 - 70	1.85
5011-S27-010-120	BT40xSAF10C-120	185.4	120	52	10	24	BT40 x SAF25	SFC10 - 70	1.90
5011-S27-012-120	BT40xSAF12C-120	185.4	120	52	12	24	BT40 x SAF25	SFC12 - 70	1.88
5011-S27-016-125	BT40xSAF16C-125	190.4	125	57	16	27	BT40 x SAF25	SFC16 - 75	1.93
5011-S27-020-130	BT40xSAF20C-130	195.4	130	60	20	33	BT40 x SAF40	SFC20 - 80	2.67
5011-S27-025-150	BT40xSAF25C-150	215.4	150	81	25	44	BT40 x SAF40	SFC25 - 100	3.20
5011-S27-032-150	BT40xSAF32C-150	215.4	150	81	32	44	BT40 x SAF40	SFC32 - 100	3.06
5012-S27-006-130	BT50xSAF6C-130	231.8	130	52	6	21	BT50 x SAF25	SFC6 - 70	4.34
5012-S27-008-130	BT50xSAF8C-130	231.8	130	52	8	21	BT50 x SAF25	SFC8 - 70	4.33
5012-S27-010-130	BT50xSAF10C-130	231.8	130	52	10	24	BT50 x SAF25	SFC10 - 70	4.38
5012-S27-012-130	BT50xSAF12C-130	231.8	130	52	12	24	BT50 x SAF25	SFC12 - 70	4.36
5012-S27-016-135	BT50xSAF16C-135	236.8	135	57	16	27	BT50 x SAF25	SFC16 - 75	4.41
5012-S27-020-140	BT50xSAF20C-140	241.8	140	60	20	33	BT50 x SAF40	SFC20 - 80	5.26
5012-S27-025-160	BT50xSAF25C-160	261.8	160	81	25	44	BT50 x SAF40	SFC25 - 100	5.79
5012-S27-032-160	BT50xSAF32C-160	261.8	160	81	32	44	BT50 x SAF40	SFC32 - 100	5.65

BT/SAF可調式刀桿 (SK3)

proimages/Products/Tool_holders/SAF/BT-SAF-SK3_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5010-S28-006-090	BT30xSAF6K-90	138.4	90	29	19.5	BT30 x SAF25	SK306 - 50	SKS6	1.00
5010-S28-010-090	BT30xSAF10K-90	138.4	90	32.5	27.5	BT30 x SAF25	SK310 - 50	SKS10	1.03
5010-S28-013-110	BT30xSAF13K-110	158.4	110	53	33	BT30 x SAF25	SK313 - 70	SKS13	1.16
5011-S28-006-100	BT40xSAF6K-100	165.4	100	29	19.5	BT40 x SAF25	SK306 - 50	SKS6	1.73
5011-S28-006-150	BT40xSAF6K-150	215.4	150	79	19.5	BT40 x SAF25	SK306 - 100	SKS6	1.82
5011-S28-010-100	BT40xSAF10K-100	165.4	100	32.5	27.5	BT40 x SAF25	SK310 - 50	SKS10	1.76
5011-S28-010-150	BT40xSAF10K-150	215.4	150	82.5	27.5	BT40 x SAF25	SK310 - 100	SKS10	1.95
5011-S28-013-120	BT40xSAF13K-120	185.4	120	53	33	BT40 x SAF25	SK313 - 70	SKS13	1.89
5011-S28-013-150	BT40xSAF13K-150	215.4	150	83	33	BT40 x SAF25	SK313 - 100	SKS13	2.07
5011-S28-016-120	BT40xSAF16K-120	185.4	120	49.9	40	BT40 x SAF40	SK316 - 70	SKS16	2.56
5011-S28-016-150	BT40xSAF16K-150	215.4	150	79.9	40	BT40 x SAF40	SK316 - 100	SKS16	2.82
5012-S28-006-110	BT50xSAF6K-110	211.8	110	29	19.5	BT50 x SAF25	SK306 - 50	SKS6	4.21
5012-S28-006-160	BT50xSAF6K-160	261.8	160	79	19.5	BT50 x SAF25	SK306 - 100	SKS6	4.30
5012-S28-010-110	BT50xSAF10K-110	211.8	110	32.5	27.5	BT50 x SAF25	SK310 - 50	SKS10	4.24
5012-S28-010-160	BT50xSAF10K-160	261.8	160	82.5	27.5	BT50 x SAF25	SK310 - 100	SKS10	4.43
5012-S28-013-130	BT50xSAF13K-130	231.8	130	53	33	BT50 x SAF25	SK313 - 70	SKS13	4.37
5012-S28-013-160	BT50xSAF13K-160	261.8	160	83	33	BT50 x SAF25	SK313 - 100	SKS13	4.55
5012-S28-016-130	BT50xSAF16K-130	231.8	130	49.9	40	BT50 x SAF40	SK316 - 70	SKS16	5.15
5012-S28-016-160	BT50xSAF16K-160	261.8	160	79.9	40	BT50 x SAF40	SK316 - 100	SKS16	5.41

BT/SAF可調式刀桿 (UT)

proimages/Products/Tool_holders/SAF/BT-SAF-UT_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5010-S30-016-090	BT30xSAF16U-90	138.4	90	32	30	BT30 x SAF25	UT16 - 50	ER16	1.08
5010-S30-020-090	BT30xSAF20U-90	138.4	90	33	35	BT30 x SAF25	UT20 - 50	ER20	1.10
5011-S30-016-100	BT40xSAF16U-100	165.4	100	32	30	BT40 x SAF25	UT16 - 50	ER16	1.81
5011-S30-020-100	BT40xSAF20U-100	165.4	100	33	35	BT40 x SAF25	UT20 - 50	ER20	1.83
5011-S30-025-110	BT40xSAF25U-110	175.4	110	38.9	42	BT40 x SAF40	UT25 - 60	ER25	2.57
5011-S30-032-110	BT40xSAF32U-110	175.4	110	40.9	48	BT40 x SAF40	UT32 - 60	ER32	2.60
5012-S30-016-110	BT50xSAF16U-110	211.8	110	32	30	BT50 x SAF25	UT16 - 50	ER16	4.29
5012-S30-020-110	BT50xSAF20U-110	211.8	110	33	35	BT50 x SAF25	UT20 - 50	ER20	4.31
5012-S30-025-120	BT50xSAF25U-120	221.8	120	38.9	42	BT50 x SAF40	UT25 - 60	ER25	5.16
5012-S30-032-120	BT50xSAF32U-120	221.8	120	40.9	48	BT50 x SAF40	UT32 - 60	ER32	5.19

CAT/SAF可調式刀桿 (SFC)

proimages/Products/Tool_holders/SAF/CAT-SAF-SFC-4.5_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	d2	COMBINATION		WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	d2	BODY	FLANGE ADAPTER	WEIGHT (KGS)
5031-S27-006-120	CAT40xSAF6C-120	188.249	120	52	6	21	CAT40 x SAF25	SFC6 - 70	1.71
5031-S27-008-120	CAT40xSAF8C-120	188.249	120	52	8	21	CAT40 x SAF25	SFC8 - 70	1.70
5031-S27-010-120	CAT40xSAF10C-120	188.249	120	52	10	24	CAT40 x SAF25	SFC10 - 70	1.75
5031-S27-012-120	CAT40xSAF12C-120	188.249	120	52	12	24	CAT40 x SAF25	SFC12 - 70	1.73
5031-S27-016-125	CAT40xSAF16C-125	193.249	125	57	16	27	CAT40 x SAF25	SFC16 - 75	1.78
5031-S27-020-140	CAT40xSAF20C-140	208.249	140	60	20	33	CAT40 x SAF40	SFC20 - 80	2.90
5031-S27-025-160	CAT40xSAF25C-160	228.249	160	81	25	44	CAT40 x SAF40	SFC25 - 100	3.43
5031-S27-032-160	CAT40xSAF32C-160	228.249	160	81	32	44	CAT40 x SAF40	SFC32 - 100	3.29
5032-S27-006-130	CAT50xSAF6C-130	231.6	130	52	6	21	CAT50 x SAF25	SFC6 - 70	3.98
5032-S27-008-130	CAT50xSAF8C-130	231.6	130	52	8	21	CAT50 x SAF25	SFC8 - 70	3.97
5032-S27-010-130	CAT50xSAF10C-130	231.6	130	52	10	24	CAT50 x SAF25	SFC10 - 70	4.02
5032-S27-012-130	CAT50xSAF12C-130	231.6	130	52	12	24	CAT50 x SAF25	SFC12 - 70	4.00
5032-S27-016-135	CAT50xSAF16C-135	236.6	135	57	16	27	CAT50 x SAF25	SFC16 - 75	4.05
5032-S27-020-140	CAT50xSAF20C-140	241.6	140	60	20	33	CAT50 x SAF40	SFC20 - 80	4.96
5032-S27-025-160	CAT50xSAF25C-160	261.6	160	81	25	44	CAT50 x SAF40	SFC25 - 100	5.49
5032-S27-032-160	CAT50xSAF32C-160	261.6	160	81	32	44	CAT50 x SAF40	SFC32 - 100	5.35

CAT/SAF可調式刀桿 (SK3)

proimages/Products/Tool_holders/SAF/CAT-SAF-SK3_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5031-S28-006-100	CAT40xSAF6K-100	168.249	100	29	19.5	CAT40 x SAF25	SK306 - 50	SKS6	1.58
5031-S28-006-150	CAT40xSAF6K-150	218.249	150	79	19.5	CAT40 x SAF25	SK306 - 100	SKS6	1.67
5031-S28-010-100	CAT40xSAF10K-100	168.249	100	32.5	27.5	CAT40 x SAF25	SK310 - 50	SKS10	1.61
5031-S28-010-150	CAT40xSAF10K-150	218.249	150	82.5	27.5	CAT40 x SAF25	SK310 - 100	SKS10	1.80
5031-S28-013-120	CAT40xSAF13K-120	188.249	120	53	33	CAT40 x SAF25	SK313 - 70	SKS13	1.74
5031-S28-013-150	CAT40xSAF13K-150	218.249	150	83	33	CAT40 x SAF25	SK313 - 100	SKS13	1.92
5031-S28-016-130	CAT40xSAF16K-130	198.249	130	49.9	40	CAT40 x SAF40	SK316 - 70	SKS16	2.79
5031-S28-016-160	CAT40xSAF16K-160	228.249	160	79.9	40	CAT40 x SAF40	SK316 - 100	SKS16	3.05
5032-S28-006-110	CAT50xSAF6K-110	211.6	110	29	19.5	CAT50 x SAF25	SK306 - 50	SKS6	3.85
5032-S28-006-160	CAT50xSAF6K-160	261.6	160	79	19.5	CAT50 x SAF25	SK306 - 100	SKS6	3.94
5032-S28-010-110	CAT50xSAF10K-110	211.6	110	32.5	27.5	CAT50 x SAF25	SK310 - 50	SKS10	3.88
5032-S28-010-160	CAT50xSAF10K-160	261.6	160	82.5	27.5	CAT50 x SAF25	SK310 - 100	SKS10	4.07
5032-S28-013-130	CAT50xSAF13K-130	231.6	130	53	33	CAT50 x SAF25	SK313 - 70	SKS13	4.01
5032-S28-013-160	CAT50xSAF13K-160	261.6	160	83	33	CAT50 x SAF25	SK313 - 100	SKS13	4.19
5032-S28-016-130	CAT50xSAF16K-130	231.6	130	49.9	40	CAT50 x SAF40	SK316 - 70	SKS16	4.85
5032-S28-016-160	CAT50xSAF16K-160	261.6	160	79.9	40	CAT50 x SAF40	SK316 - 100	SKS16	5.11

CAT/SAF可調式刀桿 (UT)

proimages/Products/Tool_holders/SAF/CAT-SAF-UT_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5031-S30-016-100	CAT40xSAF16U-100	168.249	100	32	30	CAT40 x SAF25	UT16 - 50	ER16	1.66
5031-S30-020-100	CAT40xSAF20U-100	168.249	100	33	35	CAT40 x SAF25	UT20 - 50	ER20	1.68
5031-S30-025-120	CAT40xSAF25U-120	188.249	120	38.9	42	CAT40 x SAF40	UT25 - 60	ER25	2.80
5031-S30-032-120	CAT40xSAF32U-120	188.249	120	40.9	48	CAT40 x SAF40	UT32 - 60	ER32	2.83
5032-S30-016-110	CAT50xSAF16U-110	211.6	110	32	30	CAT50 x SAF25	UT16 - 50	ER16	3.93
5032-S30-020-110	CAT50xSAF20U-110	211.6	110	33	35	CAT50 x SAF25	UT20 - 50	ER20	3.95
5032-S30-025-120	CAT50xSAF25U-120	221.6	120	38.9	42	CAT50 x SAF40	UT25 - 60	ER25	4.86
5032-S30-032-120	CAT50xSAF32U-120	221.6	120	40.9	48	CAT50 x SAF40	UT32 - 60	ER32	4.89

DAT/SAF可調式刀桿 (SFC)

proimages/Products/Tool_holders/SAF/DAT-SAF-SFC-4.5.jpg

MODEL NO.	TYPE	L	l1	l2	d1	d2	COMBINATION		WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	d2	BODY	FLANGE ADAPTER	WEIGHT (KGS)
5051-S27-006-120	DAT40xSAF6C-120	188.4	120	52	6	21	DAT40 x SAF25	SFC6 - 70	1.74
5051-S27-008-120	DAT40xSAF8C-120	188.4	120	52	8	21	DAT40 x SAF25	SFC8 - 70	1.73
5051-S27-010-120	DAT40xSAF10C-120	188.4	120	52	10	24	DAT40 x SAF25	SFC10 - 70	1.78
5051-S27-012-120	DAT40xSAF12C-120	188.4	120	52	12	24	DAT40 x SAF25	SFC12 - 70	1.76
5051-S27-016-125	DAT40xSAF16C-125	193.4	125	57	16	27	DAT40 x SAF25	SFC16 - 75	1.81
5051-S27-020-140	DAT40xSAF20C-140	208.4	140	60	20	33	DAT40 x SAF40	SFC20 - 80	2.92
5051-S27-025-160	DAT40xSAF25C-160	228.4	160	81	25	44	DAT40 x SAF40	SFC25 - 100	3.45
5051-S27-032-160	DAT40xSAF32C-160	228.4	160	81	32	44	DAT40 x SAF40	SFC32 - 100	3.31
5052-S27-006-130	DAT50xSAF6C-130	231.75	130	52	6	21	DAT50 x SAF25	SFC6 - 70	3.88
5052-S27-008-130	DAT50xSAF8C-130	231.75	130	52	8	21	DAT50 x SAF25	SFC8 - 70	3.87
5052-S27-010-130	DAT50xSAF10C-130	231.75	130	52	10	24	DAT50 x SAF25	SFC10 - 70	3.92
5052-S27-012-130	DAT50xSAF12C-130	231.75	130	52	12	24	DAT50 x SAF25	SFC12 - 70	3.90
5052-S27-016-135	DAT50xSAF16C-135	236.75	135	57	16	27	DAT50 x SAF25	SFC16 - 75	3.95
5052-S27-020-140	DAT50xSAF20C-140	241.75	140	60	20	33	DAT50 x SAF40	SFC20 - 80	5.11
5052-S27-025-160	DAT50xSAF25C-160	261.75	160	81	25	44	DAT50 x SAF40	SFC25 - 100	5.64
5052-S27-032-160	DAT50xSAF32C-160	261.75	160	81	32	44	DAT50 x SAF40	SFC32 - 100	5.50

DAT/SAF可調式刀桿 (SK3)

proimages/Products/Tool_holders/SAF/DAT-SAF-SK3_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5051-S28-006-100	DAT40xSAF6K-100	168.4	100	29	19.5	DAT40 x SAF25	SK306 - 50	SKS6	1.61
5051-S28-006-150	DAT40xSAF6K-150	218.4	150	79	19.5	DAT40 x SAF25	SK306 - 100	SKS6	1.70
5051-S28-010-100	DAT40xSAF10K-100	168.4	100	32.5	27.5	DAT40 x SAF25	SK310 - 50	SKS10	1.64
5051-S28-010-150	DAT40xSAF10K-150	218.4	150	82.5	27.5	DAT40 x SAF25	SK310 - 100	SKS10	1.83
5051-S28-013-120	DAT40xSAF13K-120	188.4	120	53	33	DAT40 x SAF25	SK313 - 70	SKS13	1.77
5051-S28-013-150	DAT40xSAF13K-150	218.4	150	83	33	DAT40 x SAF25	SK313 - 100	SKS13	1.95
5051-S28-016-130	DAT40xSAF16K-130	198.4	130	49.9	40	DAT40 x SAF40	SK316 - 70	SKS16	2.81
5051-S28-016-160	DAT40xSAF16K-160	228.4	160	79.9	40	DAT40 x SAF40	SK316 - 100	SKS16	3.07
5052-S28-006-110	DAT50xSAF6K-110	211.75	110	29	19.5	DAT50 x SAF25	SK306 - 50	SKS6	3.75
5052-S28-006-160	DAT50xSAF6K-160	261.75	160	79	19.5	DAT50 x SAF25	SK306 - 100	SKS6	3.84
5052-S28-010-110	DAT50xSAF10K-110	211.75	110	32.5	27.5	DAT50 x SAF25	SK310 - 50	SKS10	3.78
5052-S28-010-160	DAT50xSAF10K-160	261.75	160	82.5	27.5	DAT50 x SAF25	SK310 - 100	SKS10	3.97
5052-S28-013-130	DAT50xSAF13K-130	231.75	130	53	33	DAT50 x SAF25	SK313 - 70	SKS13	3.91
5052-S28-013-160	DAT50xSAF13K-160	261.75	160	83	33	DAT50 x SAF25	SK313 - 100	SKS13	4.09
5052-S28-016-130	DAT50xSAF16K-130	231.75	130	49.9	40	DAT50 x SAF40	SK316 - 70	SKS16	5.00
5052-S28-016-160	DAT50xSAF16K-160	261.75	160	79.9	40	DAT50 x SAF40	SK316 - 100	SKS16	5.26

DAT/SAF可調式刀桿 (UT)

proimages/Products/Tool_holders/SAF/DAT-SAF-UT_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5051-S30-016-100	DAT40xSAF16U-100	168.4	100	32	30	DAT40 x SAF25	UT16 - 50	ER16	1.69
5051-S30-020-100	DAT40xSAF20U-100	168.4	100	33	35	DAT40 x SAF25	UT20 - 50	ER20	1.71
5051-S30-025-120	DAT40xSAF25U-120	188.4	120	38.9	42	DAT40 x SAF40	UT25 - 60	ER25	2.82
5051-S30-032-120	DAT40xSAF32U-120	188.4	120	40.9	48	DAT40 x SAF40	UT32 - 60	ER32	2.85
5052-S30-016-110	DAT50xSAF16U-110	211.75	110	32	30	DAT50 x SAF25	UT16 - 50	ER16	3.83
5052-S30-020-110	DAT50xSAF20U-110	211.75	110	33	35	DAT50 x SAF25	UT20 - 50	ER20	3.85
5052-S30-025-120	DAT50xSAF25U-120	221.75	120	38.9	42	DAT50 x SAF40	UT25 - 60	ER25	5.01
5052-S30-032-120	DAT50xSAF32U-120	221.75	120	40.9	48	DAT50 x SAF40	UT32 - 60	ER32	5.04

SBT/SAF法蘭加厚型可調式刀桿 (SFC)

proimages/Products/Tool_holders/SAF/SBT-SAF-SFC-4.5_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	d2	COMBINATION		WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	d2	BODY	FLANGE ADAPTER	WEIGHT (KGS)
5025-S27-006-110	SBT30xSAF6C-110	158.4	110	52	6	21	SBT30 x SAF25	SFC6 - 70	1.13
5025-S27-008-110	SBT30xSAF8C-110	158.4	110	52	8	21	SBT30 x SAF25	SFC8 - 70	1.12
5025-S27-010-110	SBT30xSAF10C-110	158.4	110	52	10	24	SBT30 x SAF25	SFC10 - 70	1.17
5025-S27-012-110	SBT30xSAF12C-110	158.4	110	52	12	24	SBT30 x SAF25	SFC12 - 70	1.15
5025-S27-016-115	SBT30xSAF16C-115	163.4	115	57	16	27	SBT30 x SAF25	SFC16 - 75	1.20
5026-S27-006-120	SBT40xSAF6C-120	185.4	120	52	6	21	SBT40 x SAF25	SFC6 - 70	1.87
5026-S27-008-120	SBT40xSAF8C-120	185.4	120	52	8	21	SBT40 x SAF25	SFC8 - 70	1.86
5026-S27-010-120	SBT40xSAF10C-120	185.4	120	52	10	24	SBT40 x SAF25	SFC10 - 70	1.91
5026-S27-012-120	SBT40xSAF12C-120	185.4	120	52	12	24	SBT40 x SAF25	SFC12 - 70	1.89
5026-S27-016-125	SBT40xSAF16C-125	190.4	125	57	16	27	SBT40 x SAF25	SFC16 - 75	1.94
5026-S27-020-130	SBT40xSAF20C-130	195.4	130	60	20	33	SBT40 x SAF40	SFC20 - 80	2.68
5026-S27-025-150	SBT40xSAF25C-150	215.4	150	81	25	44	SBT40 x SAF40	SFC25 - 100	3.21
5026-S27-032-150	SBT40xSAF32C-150	215.4	150	81	32	44	SBT40 x SAF40	SFC32 - 100	3.07
5027-S27-006-130	SBT50xSAF6C-130	231.8	130	52	6	21	SBT50 x SAF25	SFC6 - 70	4.38
5027-S27-008-130	SBT50xSAF8C-130	231.8	130	52	8	21	SBT50 x SAF25	SFC8 - 70	4.37
5027-S27-010-130	SBT50xSAF10C-130	231.8	130	52	10	24	SBT50 x SAF25	SFC10 - 70	4.42
5027-S27-012-130	SBT50xSAF12C-130	231.8	130	52	12	24	SBT50 x SAF25	SFC12 - 70	4.40
5027-S27-016-135	SBT50xSAF16C-135	236.8	135	57	16	27	SBT50 x SAF25	SFC16 - 75	4.45
5027-S27-020-140	SBT50xSAF20C-140	241.8	140	60	20	33	SBT50 x SAF40	SFC20 - 80	5.30
5027-S27-025-160	SBT50xSAF25C-160	261.8	160	81	25	44	SBT50 x SAF40	SFC25 - 100	5.83
5027-S27-032-160	SBT50xSAF32C-160	261.8	160	81	32	44	SBT50 x SAF40	SFC32 - 100	5.69

SBT/SAF法蘭加厚型可調式刀桿 (SK3)

proimages/Products/Tool_holders/SAF/SBT-SAF-SK3_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5025-S28-006-090	SBT30xSAF6K-90	138.4	90	29	19.5	SBT30 x SAF25	SK306 - 50	SKS6	1.00
5025-S28-010-090	SBT30xSAF10K-90	138.4	90	32.5	27.5	SBT30 x SAF25	SK310 - 50	SKS10	1.03
5025-S28-013-110	SBT30xSAF13K-110	158.4	110	53	33	SBT30 x SAF25	SK313 - 70	SKS13	1.16
5026-S28-006-100	SBT40xSAF6K-100	165.4	100	29	19.5	SBT40 x SAF25	SK306 - 50	SKS6	1.74
5026-S28-006-150	SBT40xSAF6K-150	215.4	150	79	19.5	SBT40 x SAF25	SK306 - 100	SKS6	1.83
5026-S28-010-100	SBT40xSAF10K-100	165.4	100	32.5	27.5	SBT40 x SAF25	SK310 - 50	SKS10	1.77
5026-S28-010-150	SBT40xSAF10K-150	215.4	150	82.5	27.5	SBT40 x SAF25	SK310 - 100	SKS10	1.96
5026-S28-013-120	SBT40xSAF13K-120	185.4	120	53	33	SBT40 x SAF25	SK313 - 70	SKS13	1.90
5026-S28-013-150	SBT40xSAF13K-150	215.4	150	83	33	SBT40 x SAF25	SK313 - 100	SKS13	2.08
5026-S28-016-120	SBT40xSAF16K-120	185.4	120	49.9	40	SBT40 x SAF40	SK316 - 70	SKS16	2.57
5026-S28-016-150	SBT40xSAF16K-150	215.4	150	79.9	40	SBT40 x SAF40	SK316 - 100	SKS16	2.83
5027-S28-006-110	SBT50xSAF6K-110	211.8	110	29	19.5	SBT50 x SAF25	SK306 - 50	SKS6	4.25
5027-S28-006-160	SBT50xSAF6K-160	261.8	160	79	19.5	SBT50 x SAF25	SK306 - 100	SKS6	4.34
5027-S28-010-110	SBT50xSAF10K-110	211.8	110	32.5	27.5	SBT50 x SAF25	SK310 - 50	SKS10	4.28
5027-S28-010-160	SBT50xSAF10K-160	261.8	160	82.5	27.5	SBT50 x SAF25	SK310 - 100	SKS10	4.47
5027-S28-013-130	SBT50xSAF13K-130	231.8	130	53	33	SBT50 x SAF25	SK313 - 70	SKS13	4.41
5027-S28-013-160	SBT50xSAF13K-160	261.8	160	83	33	SBT50 x SAF25	SK313 - 100	SKS13	4.59
5027-S28-016-130	SBT50xSAF16K-130	231.8	130	49.9	40	SBT50 x SAF40	SK316 - 70	SKS16	5.19
5027-S28-016-160	SBT50xSAF16K-160	261.8	160	79.9	40	SBT50 x SAF40	SK316 - 100	SKS16	5.45

SBT/SAF法蘭加厚型可調式刀桿 (UT)

proimages/Products/Tool_holders/SAF/SBT-SAF-UT_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5025-S30-016-090	SBT30xSAF16U-90	138.4	90	32	30	SBT30 x SAF25	UT16 - 50	ER16	1.08
5025-S30-020-090	SBT30xSAF20U-90	138.4	90	33	35	SBT30 x SAF25	UT20 - 50	ER20	1.10
5026-S30-016-100	SBT40xSAF16U-100	165.4	100	32	30	SBT40 x SAF25	UT16 - 50	ER16	1.82
5026-S30-020-100	SBT40xSAF20U-100	165.4	100	33	35	SBT40 x SAF25	UT20 - 50	ER20	1.84
5026-S30-025-110	SBT40xSAF25U-110	175.4	110	38.9	42	SBT40 x SAF40	UT25 - 60	ER25	2.58
5026-S30-032-110	SBT40xSAF32U-110	175.4	110	40.9	48	SBT40 x SAF40	UT32 - 60	ER32	2.61
5027-S30-016-110	SBT50xSAF16U-110	211.8	110	32	30	SBT50 x SAF25	UT16 - 50	ER16	4.33
5027-S30-020-110	SBT50xSAF20U-110	211.8	110	33	35	SBT50 x SAF25	UT20 - 50	ER20	4.35
5027-S30-025-120	SBT50xSAF25U-120	221.8	120	38.9	42	SBT50 x SAF40	UT25 - 60	ER25	5.20
5027-S30-032-120	SBT50xSAF32U-120	221.8	120	40.9	48	SBT50 x SAF40	UT32 - 60	ER32	5.23

SCAT/SAF法蘭加厚型可調式刀桿 (SFC)

proimages/Products/Tool_holders/SAF/SCAT-SAF-SFC-4.5_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	d2	COMBINATION		WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	d2	BODY	FLANGE ADAPTER	WEIGHT (KGS)
5043-S27-006-120	SCAT40xSAF6C-120	188.249	120	52	6	21	SCAT40 x SAF25	SFC6 - 70	1.74
5043-S27-008-120	SCAT40xSAF8C-120	188.249	120	52	8	21	SCAT40 x SAF25	SFC8 - 70	1.73
5043-S27-010-120	SCAT40xSAF10C-120	188.249	120	52	10	24	SCAT40 x SAF25	SFC10 - 70	1.78
5043-S27-012-120	SCAT40xSAF12C-120	188.249	120	52	12	24	SCAT40 x SAF25	SFC12 - 70	1.76
5043-S27-016-125	SCAT40xSAF16C-125	193.249	125	57	16	27	SCAT40 x SAF25	SFC16 - 75	1.81
5043-S27-020-140	SCAT40xSAF20C-140	208.249	140	60	20	33	SCAT40 x SAF40	SFC20 - 80	2.92
5043-S27-025-160	SCAT40xSAF25C-160	228.249	160	81	25	44	SCAT40 x SAF40	SFC25 - 100	3.45
5043-S27-032-160	SCAT40xSAF32C-160	228.249	160	81	32	44	SCAT40 x SAF40	SFC32 - 100	3.31
5044-S27-006-130	SCAT50xSAF6C-130	231.6	130	52	6	21	SCAT50 x SAF25	SFC6 - 70	4.02
5044-S27-008-130	SCAT50xSAF8C-130	231.6	130	52	8	21	SCAT50 x SAF25	SFC8 - 70	4.01
5044-S27-010-130	SCAT50xSAF10C-130	231.6	130	52	10	24	SCAT50 x SAF25	SFC10 - 70	4.06
5044-S27-012-130	SCAT50xSAF12C-130	231.6	130	52	12	24	SCAT50 x SAF25	SFC12 - 70	4.04
5044-S27-016-135	SCAT50xSAF16C-135	236.6	135	57	16	27	SCAT50 x SAF25	SFC16 - 75	4.09
5044-S27-020-140	SCAT50xSAF20C-140	241.6	140	60	20	33	SCAT50 x SAF40	SFC20 - 80	5.00
5044-S27-025-160	SCAT50xSAF25C-160	261.6	160	81	25	44	SCAT50 x SAF40	SFC25 - 100	5.53
5044-S27-032-160	SCAT50xSAF32C-160	261.6	160	81	32	44	SCAT50 x SAF40	SFC32 - 100	5.39

SCAT/SAF法蘭加厚型可調式刀桿 (SK3)

proimages/Products/Tool_holders/SAF/SCAT-SAF-SK3_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5043-S28-006-100	SCAT40xSAF6K-100	168.249	100	29	19.5	SCAT40 x SAF25	SK306 - 50	SKS6	1.61
5043-S28-006-150	SCAT40xSAF6K-150	218.249	150	79	19.5	SCAT40 x SAF25	SK306 - 100	SKS6	1.70
5043-S28-010-100	SCAT40xSAF10K-100	168.249	100	32.5	27.5	SCAT40 x SAF25	SK310 - 50	SKS10	1.64
5043-S28-010-150	SCAT40xSAF10K-150	218.249	150	82.5	27.5	SCAT40 x SAF25	SK310 - 100	SKS10	1.83
5043-S28-013-120	SCAT40xSAF13K-120	188.249	120	53	33	SCAT40 x SAF25	SK313 - 70	SKS13	1.77
5043-S28-013-150	SCAT40xSAF13K-150	218.249	150	83	33	SCAT40 x SAF25	SK313 - 100	SKS13	1.95
5043-S28-016-130	SCAT40xSAF16K-130	198.249	130	49.9	40	SCAT40 x SAF40	SK316 - 70	SKS16	2.81
5043-S28-016-160	SCAT40xSAF16K-160	228.249	160	79.9	40	SCAT40 x SAF40	SK316 - 100	SKS16	3.07
5044-S28-006-110	SCAT50xSAF6K-110	211.6	110	29	19.5	SCAT50 x SAF25	SK306 - 50	SKS6	3.89
5044-S28-006-160	SCAT50xSAF6K-160	261.6	160	79	19.5	SCAT50 x SAF25	SK306 - 100	SKS6	3.98
5044-S28-010-110	SCAT50xSAF10K-110	211.6	110	32.5	27.5	SCAT50 x SAF25	SK310 - 50	SKS10	3.92
5044-S28-010-160	SCAT50xSAF10K-160	261.6	160	82.5	27.5	SCAT50 x SAF25	SK310 - 100	SKS10	4.11
5044-S28-013-130	SCAT50xSAF13K-130	231.6	130	53	33	SCAT50 x SAF25	SK313 - 70	SKS13	4.05
5044-S28-013-160	SCAT50xSAF13K-160	261.6	160	83	33	SCAT50 x SAF25	SK313 - 100	SKS13	4.23
5044-S28-016-130	SCAT50xSAF16K-130	231.6	130	49.9	40	SCAT50 x SAF40	SK316 - 70	SKS16	4.89
5044-S28-016-160	SCAT50xSAF16K-160	261.6	160	79.9	40	SCAT50 x SAF40	SK316 - 100	SKS16	5.15

SCAT/SAF法蘭加厚型可調式刀桿 (UT)

proimages/Products/Tool_holders/SAF/SCAT-SAF-UT_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5043-S30-160-100	SCAT40xSAF16U-100	168.249	100	32	30	SCAT40 x SAF25	UT16 - 50	ER16	1.69
5043-S30-020-100	SCAT40xSAF20U-100	168.249	100	33	35	SCAT40 x SAF25	UT20 - 50	ER20	1.71
5043-S30-025-120	SCAT40xSAF25U-120	188.249	120	38.9	42	SCAT40 x SAF40	UT25 - 60	ER25	2.82
5043-S30-032-120	SCAT40xSAF32U-120	188.249	120	40.9	48	SCAT40 x SAF40	UT32 - 60	ER32	2.85
5044-S30-016-110	SCAT50xSAF16U-110	211.6	110	32	30	SCAT50 x SAF25	UT16 - 50	ER16	3.97
5044-S30-020-110	SCAT50xSAF20U-110	211.6	110	33	35	SCAT50 x SAF25	UT20 - 50	ER20	3.99
5044-S30-025-120	SCAT50xSAF25U-120	221.6	120	38.9	42	SCAT50 x SAF40	UT25 - 60	ER25	4.90
5044-S30-032-120	SCAT50xSAF32U-120	221.6	120	40.9	48	SCAT50 x SAF40	UT32 - 60	ER32	4.93

SDAT/SAF法蘭加厚型可調式刀桿 (SFC)

proimages/Products/Tool_holders/SAF/SDAT-SAF-SFC-4.5_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	d2	COMBINATION		WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	d2	BODY	FLANGE ADAPTER	WEIGHT (KGS)
5066-S27-006-120	SDAT40xSAF6C-120	188.4	120	52	6	21	SDAT40 x SAF25	SFC6 - 70	1.76
5066-S27-008-120	SDAT40xSAFC8-120	188.4	120	52	8	21	SDAT40 x SAF25	SFC8 - 70	1.75
5066-S27-010-120	SDAT40xSAF10C-120	188.4	120	52	10	24	SDAT40 x SAF25	SFC10 - 70	1.80
5066-S27-012-120	SDAT40xSAF12C-120	188.4	120	52	12	24	SDAT40 x SAF25	SFC12 - 70	1.78
5066-S27-016-125	SDAT40xSAF16C-125	193.4	125	57	16	27	SDAT40 x SAF25	SFC16 - 75	1.83
5066-S27-020-140	SDAT40xSAF20C-140	208.4	140	60	20	33	SDAT40 x SAF40	SFC20 - 80	2.94
5066-S27-025-160	SDAT40xSAF25C-160	228.4	160	81	25	44	SDAT40 x SAF40	SFC25 - 100	3.47
5066-S27-032-160	SDAT40xSAF32C-160	228.4	160	81	32	44	SDAT40 x SAF40	SFC32 - 100	3.33
5067-S27-006-130	SDAT50xSAF6C-130	231.75	130	52	6	21	SDAT50 x SAF25	SFC6 - 70	3.92
5067-S27-008-130	SDAT50xSAF8C-130	231.75	130	52	8	21	SDAT50 x SAF25	SFC8 - 70	3.91
5067-S27-010-130	SDAT50xSAF10C-130	231.75	130	52	10	24	SDAT50 x SAF25	SFC10 - 70	3.96
5067-S27-012-130	SDAT50xSAF12C-130	231.75	130	52	12	24	SDAT50 x SAF25	SFC12 - 70	3.94
5067-S27-016-135	SDAT50xSAF16C-135	236.75	135	57	16	27	SDAT50 x SAF25	SFC16 - 75	3.99
5067-S27-020-140	SDAT50xSAF20C-140	241.75	140	60	20	33	SDAT50 x SAF40	SFC20 - 80	5.15
5067-S27-025-160	SDAT50xSAF25C-160	261.75	160	81	25	44	SDAT50 x SAF40	SFC25 - 100	5.68
5067-S27-032-160	SDAT50xSAF32C-160	261.75	160	81	32	44	SDAT50 x SAF40	SFC32 - 100	5.54

SDAT/SAF法蘭加厚型可調式刀桿 (SK3)

proimages/Products/Tool_holders/SAF/SDAT-SAF-SK3_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5066-S28-006-100	SDAT40xSAF6K-100	168.4	100	29	19.5	SDAT40 x SAF25	SK306 - 50	SKS6	1.63
5066-S28-006-150	SDAT40xSAF6K-150	218.4	150	79	19.5	SDAT40 x SAF25	SK306 - 100	SKS6	1.72
5066-S28-010-100	SDAT40xSAF10K-100	168.4	100	32.5	27.5	SDAT40 x SAF25	SK310 - 50	SKS10	1.66
5066-S28-010-150	SDAT40xSAF10K-150	218.4	150	82.5	27.5	SDAT40 x SAF25	SK310 - 100	SKS10	1.85
5066-S28-013-120	SDAT40xSAF13K-120	188.4	120	53	33	SDAT40 x SAF25	SK313 - 70	SKS13	1.79
5066-S28-013-150	SDAT40xSAF13K-150	218.4	150	83	33	SDAT40 x SAF25	SK313 - 100	SKS13	1.97
5066-S28-016-130	SDAT40xSAF16K-130	198.4	130	49.9	40	SDAT40 x SAF40	SK316 - 70	SKS16	2.83
5066-S28-016-160	SDAT40xSAF16K-160	228.4	160	79.9	40	SDAT40 x SAF40	SK316 - 100	SKS16	3.09
5067-S28-006-110	SDAT50xSAF6K-110	211.75	110	29	19.5	SDAT50 x SAF25	SK306 - 50	SKS6	3.79
5067-S28-006-160	SDAT50xSAF6K-160	261.75	160	79	19.5	SDAT50 x SAF25	SK306 - 100	SKS6	3.88
5067-S28-010-110	SDAT50xSAF10K-110	211.75	110	32.5	27.5	SDAT50 x SAF25	SK310 - 50	SKS10	3.82
5067-S28-010-160	SDAT50xSAF10K-160	261.75	160	82.5	27.5	SDAT50 x SAF25	SK310 - 100	SKS10	4.01
5067-S28-013-130	SDAT50xSAF13K-130	231.75	130	53	33	SDAT50 x SAF25	SK313 - 70	SKS13	3.95
5067-S28-013-160	SDAT50xSAF13K-160	261.75	160	83	33	SDAT50 x SAF25	SK313 - 100	SKS13	4.13
5067-S28-016-130	SDAT50xSAF16K-130	231.75	130	49.9	40	SDAT50 x SAF40	SK316 - 70	SKS16	5.04
5067-S28-016-160	SDAT50xSAF16K-160	261.75	160	79.9	40	SDAT50 x SAF40	SK316 - 100	SKS16	5.30

SDAT/SAF法蘭加厚型可調式刀桿 (UT)

proimages/Products/Tool_holders/SAF/SDAT-SAF-UT_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5066-S30-016-100	SDAT40xSAF16U-100	168.4	100	32	30	SDAT40 x SAF25	UT16 - 50	ER16	1.71
5066-S30-020-100	SDAT40xSAF20U-100	168.4	100	33	35	SDAT40 x SAF25	UT20 - 50	ER20	1.73
5066-S30-025-120	SDAT40xSAF25U-120	188.4	120	38.9	42	SDAT40 x SAF40	UT25 - 60	ER25	2.84
5066-S30-032-120	SDAT40xSAF32U-120	188.4	120	40.9	48	SDAT40 x SAF40	UT32 - 60	ER32	2.87
5067-S30-016-110	SDAT50xSAF16U-110	211.75	110	32	30	SDAT50 x SAF25	UT16 - 50	ER16	3.87
5067-S30-020-110	SDAT50xSAF20U-110	211.75	110	33	35	SDAT50 x SAF25	UT20 - 50	ER20	3.89
5067-S30-025-120	SDAT50xSAF25U-120	221.75	120	38.9	42	SDAT50 x SAF40	UT25 - 60	ER25	5.05
5067-S30-032-120	SDAT50xSAF32U-120	221.75	120	40.9	48	SDAT50 x SAF40	UT32 - 60	ER32	5.08

HSK-A/SAF可調式刀桿 (SFC)

proimages/Products/Tool_holders/SAF/HSK-SAF-SFC-4.5_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	d2	COMBINATION		WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	d2	BODY	FLANGE ADAPTER	WEIGHT (KGS)
5071-S27-006-130	HSK40AxSAF6C-130	150	130	52	6	21	HSK40A x SAF25	SFC6 - 70	1.22
5071-S27-008-130	HSK40AxSAF8C-130	150	130	52	8	21	HSK40A x SAF25	SFC8 - 70	1.21
5071-S27-010-130	HSK40AxSAF10C-130	150	130	52	10	24	HSK40A x SAF25	SFC10 - 70	1.26
5071-S27-012-130	HSK40AxSAF12C-130	150	130	52	12	24	HSK40A x SAF25	SFC12 - 70	1.24
5071-S27-016-135	HSK40AxSAF16C-135	155	135	57	16	27	HSK40A x SAF25	SFC16 - 75	1.29
5072-S27-006-130	HSK50AxSAF6C-130	155	130	52	6	21	HSK50A x SAF25	SFC6 - 70	1.34
5072-S27-008-130	HSK50AxSAF8C-130	155	130	52	8	21	HSK50A x SAF25	SFC8 - 70	1.33
5072-S27-010-130	HSK50AxSAF10C-130	155	130	52	10	24	HSK50A x SAF25	SFC10 - 70	1.38
5072-S27-012-130	HSK50AxSAF12C-130	155	130	52	12	24	HSK50A x SAF25	SFC12 - 70	1.36
5072-S27-016-135	HSK50AxSAF16C-135	160	135	57	16	27	HSK50A x SAF25	SFC16 - 75	1.41
5073-S27-006-130	HSK63AxSAF6C-130	162	130	52	6	21	HSK63A x SAF25	SFC6 - 70	1.68
5073-S27-008-130	HSK63AxSAF8C-130	162	130	52	8	21	HSK63A x SAF25	SFC8 - 70	1.67
5073-S27-010-130	HSK63AxSAF10C-130	162	130	52	10	24	HSK63A x SAF25	SFC10 - 70	1.72
5073-S27-012-130	HSK63AxSAF12C-130	162	130	52	12	24	HSK63A x SAF25	SFC12 - 70	1.70
5073-S27-016-135	HSK63AxSAF16C-135	167	135	57	16	27	HSK63A x SAF25	SFC16 - 75	1.75
5073-S27-020-140	HSK63AxSAF20C-140	172	140	60	20	33	HSK63A x SAF40	SFC20 - 80	2.55
5073-S27-025-160	HSK63AxSAF25C-160	192	160	81	25	44	HSK63A x SAF40	SFC25 - 100	3.08
5073-S27-032-160	HSK63AxSAF32C-160	192	160	81	32	44	HSK63A x SAF40	SFC32 - 100	2.94
5074-S27-006-120	HSK80AxSAF6C-120	160	120	52	6	21	HSK80A x SAF25	SFC6 - 70	1.99
5074-S27-008-120	HSK80AxSAF8C-120	160	120	52	8	21	HSK80A x SAF25	SFC8 - 70	1.98
5074-S27-010-120	HSK80AxSAF10C-120	160	120	52	10	24	HSK80A x SAF25	SFC10 - 70	2.03
5074-S27-012-120	HSK80AxSAF12C-120	160	120	52	12	24	HSK80A x SAF25	SFC12 - 70	2.01
5074-S27-016-125	HSK80AxSAF16C-125	165	125	57	16	27	HSK80A x SAF25	SFC16 - 75	2.06
5074-S27-020-140	HSK80AxSAF20C-140	180	140	60	20	33	HSK80A x SAF40	SFC20 - 80	3.14
5074-S27-025-160	HSK80AxSAF25C-160	200	160	81	25	44	HSK80A x SAF40	SFC25 - 100	3.67
5074-S27-032-160	HSK80AxSAF32C-160	200	160	81	32	44	HSK80A x SAF40	SFC32 - 100	3.53
5075-S27-006-125	HSK100AxSAF6C-125	175	125	52	6	21	HSK100A x SAF25	SFC6 - 70	2.93
5075-S27-008-125	HSK100AxSAF8C-125	175	125	52	8	21	HSK100A x SAF25	SFC8 - 70	2.92
5075-S27-010-125	HSK100AxSAF10C-125	175	125	52	10	24	HSK100A x SAF25	SFC10 - 70	2.97
5075-S27-012-125	HSK100AxSAF12C-125	175	125	52	12	24	HSK100A x SAF25	SFC12 - 70	2.95
5075-S27-016-130	HSK100AxSAF16C-130	180	130	57	16	27	HSK100A x SAF25	SFC16 - 75	3.00
5075-S27-020-135	HSK100AxSAF20C-135	185	135	60	20	33	HSK100A x SAF40	SFC20 - 80	3.92
5075-S27-025-155	HSK100AxSAF25C-155	205	155	81	25	44	HSK100A x SAF40	SFC25 - 100	4.45
5075-S27-032-155	HSK100AxSAF32C-155	205	155	81	32	44	HSK100A x SAF40	SFC32 - 100	4.31

HSK-A/SAF可調式刀桿 (SK3)

proimages/Products/Tool_holders/SAF/HSK-SAF-SK3_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5071-S28-006-110	HSK40AxSAF6K-110	130	110	29	19.5	HSK40A x SAF25	SK306 - 50	SKS6	1.09
5071-S28-006-160	HSK40AxSAF6K-160	180	160	79	19.5	HSK40A x SAF25	SK306 - 100	SKS6	1.18
5071-S28-010-110	HSK40AxSAF10K-110	130	110	32.5	27.5	HSK40A x SAF25	SK310 - 50	SKS10	1.12
5071-S28-010-160	HSK40AxSAF10K-160	180	160	82.5	27.5	HSK40A x SAF25	SK310 - 100	SKS10	1.31
5071-S28-013-130	HSK40AxSAF13K-130	150	130	53	33	HSK40A x SAF25	SK313 - 70	SKS13	1.25
5071-S28-013-160	HSK40AxSAF13K-160	180	160	83	33	HSK40A x SAF25	SK313 - 100	SKS13	1.43
5072-S28-006-110	HSK50AxSAF6K-110	135	110	29	19.5	HSK50A x SAF25	SK306 - 50	SKS6	1.21
5072-S28-006-160	HSK50AxSAF6K-160	185	160	79	19.5	HSK50A x SAF25	SK306 - 100	SKS6	1.30
5072-S28-010-110	HSK50AxSAF10K-110	135	110	32.5	27.5	HSK50A x SAF25	SK310 - 50	SKS10	1.24
5072-S28-010-160	HSK50AxSAF10K-160	185	160	82.5	27.5	HSK50A x SAF25	SK310 - 100	SKS10	1.43
5072-S28-013-130	HSK50AxSAF13K-130	155	130	53	33	HSK50A x SAF25	SK313 - 70	SKS13	1.37
5072-S28-013-160	HSK50AxSAF13K-160	185	160	83	33	HSK50A x SAF25	SK313 - 100	SKS13	1.55
5073-S28-006-110	HSK63AxSAF6K-110	142	110	29	19.5	HSK63A x SAF25	SK306 - 50	SKS6	1.55
5073-S28-006-160	HSK63AxSAF6K-160	192	160	79	19.5	HSK63A x SAF25	SK306 - 100	SKS6	1.64
5073-S28-010-110	HSK63AxSAF10K-110	142	110	32.5	27.5	HSK63A x SAF25	SK310 - 50	SKS10	1.58
5073-S28-010-160	HSK63AxSAF10K-160	192	160	82.5	27.5	HSK63A x SAF25	SK310 - 100	SKS10	1.77
5073-S28-013-130	HSK63AxSAF13K-130	162	130	53	33	HSK63A x SAF25	SK313 - 70	SKS13	1.71
5073-S28-013-160	HSK63AxSAF13K-160	192	160	83	33	HSK63A x SAF25	SK313 - 100	SKS13	1.89
5073-S28-016-130	HSK63AxSAF16K-130	162	130	49.9	40	HSK63A x SAF40	SK316 - 70	SKS16	2.44
5073-S28-016-160	HSK63AxSAF16K-160	192	160	79.9	40	HSK63A x SAF40	SK316 - 100	SKS16	2.70
5074-S28-006-100	HSK80AxSAF6K-100	140	100	29	19.5	HSK80A x SAF25	SK306 - 50	SKS6	1.86
5074-S28-006-150	HSK80AxSAF6K-150	190	150	79	19.5	HSK80A x SAF25	SK306 - 100	SKS6	1.95
5074-S28-010-100	HSK80AxSAF10K-100	140	100	32.5	27.5	HSK80A x SAF25	SK310 - 50	SKS10	1.89
5074-S28-010-150	HSK80AxSAF10K-150	190	150	82.5	27.5	HSK80A x SAF25	SK310 - 100	SKS10	2.08
5074-S28-013-120	HSK80AxSAF13K-120	160	120	53	33	HSK80A x SAF25	SK313 - 70	SKS13	2.02
5074-S28-013-150	HSK80AxSAF13K-150	190	150	83	33	HSK80A x SAF25	SK313 - 100	SKS13	2.20
5074-S28-016-130	HSK80AxSAF16K-130	170	130	49.9	40	HSK80A x SAF40	SK316 - 70	SKS16	3.03
5074-S28-016-160	HSK80AxSAF16K-160	200	160	79.9	40	HSK80A x SAF40	SK316 - 100	SKS16	3.29
5075-S28-006-105	HSK100AxSAF6K-105	155	105	29	19.5	HSK100A x SAF25	SK306 - 50	SKS6	2.80
5075-S28-006-155	HSK100AxSAF6K-155	205	155	79	19.5	HSK100A x SAF25	SK306 - 100	SKS6	2.89
5075-S28-010-105	HSK100AxSAF10K-105	155	105	32.5	27.5	HSK100A x SAF25	SK310 - 50	SKS10	2.83
5075-S28-010-155	HSK100AxSAF10K-155	205	155	82.5	27.5	HSK100A x SAF25	SK310 - 100	SKS10	3.02
5075-S28-013-125	HSK100AxSAF13K-125	175	125	53	33	HSK100A x SAF25	SK313 - 70	SKS13	2.96
5075-S28-013-155	HSK100AxSAF13K-155	205	155	83	33	HSK100A x SAF25	SK313 - 100	SKS13	3.14
5075-S28-016-125	HSK100AxSAF16K-125	175	125	49.9	40	HSK100A x SAF40	SK316 - 70	SKS16	3.81
5075-S28-016-155	HSK100AxSAF16K-155	205	155	79.9	40	HSK100A x SAF40	SK316 - 100	SKS16	4.07

HSK-A/SAF可調式刀桿 (UT)

proimages/Products/Tool_holders/SAF/HSK-SAF-UT_fihure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5071-S30-016-110	HSK40AxSAF16U-110	130	110	32	30	HSK40A x SAF25	UT16 - 50	ER16	1.17
5071-S30-020-110	HSK40AxSAF20U-110	130	110	33	35	HSK40A x SAF25	UT20 - 50	ER20	1.19
5072-S30-016-110	HSK50AxSAF16U-110	135	110	32	30	HSK50A x SAF25	UT16 - 50	ER16	1.29
5072-S30-020-110	HSK50AxSAF20U-110	135	110	33	35	HSK50A x SAF25	UT20 - 50	ER20	1.31
5073-S30-016-110	HSK63AxSAF16U-110	142	110	32	30	HSK63A x SAF25	UT16 - 50	ER16	1.63
5073-S30-020-110	HSK63AxSAF20U-110	142	110	33	35	HSK63A x SAF25	UT20 - 50	ER20	1.65
5073-S30-025-120	HSK63AxSAF25U-120	152	120	38.9	42	HSK63A x SAF40	UT25 - 60	ER25	2.45
5073-S30-032-120	HSK63AxSAF32U-120	152	120	40.9	48	HSK63A x SAF40	UT32 - 60	ER32	2.48
5074-S30-016-100	HSK80AxSAF16U-100	140	100	32	30	HSK80A x SAF25	UT16 - 50	ER16	1.94
5074-S30-020-100	HSK80AxSAF20U-100	140	100	33	35	HSK80A x SAF25	UT20 - 50	ER20	1.96
5074-S30-025-120	HSK80AxSAF25U-120	160	120	38.9	42	HSK80A x SAF40	UT25 - 60	ER25	3.04
5074-S30-032-120	HSK80AxSAF32U-120	160	120	40.9	48	HSK80A x SAF40	UT32 - 60	ER32	3.07
5075-S30-016-105	HSK100AxSAF16U-105	155	105	32	30	HSK100A x SAF25	UT16 - 50	ER16	2.88
5075-S30-020-105	HSK100AxSAF20U-105	155	105	33	35	HSK100A x SAF25	UT20 - 50	ER20	2.90
5075-S30-025-115	HSK100AxSAF25U-115	165	115	38.9	42	HSK100A x SAF40	UT25 - 60	ER25	3.82
5075-S30-032-115	HSK100AxSAF32U-115	165	115	40.9	48	HSK100A x SAF40	UT32 - 60	ER32	3.85

PSC/SAF可調式刀桿 (SFC)

proimages/Products/Tool_holders/SAF/PSC-SAF-SFC-4.5_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	d2	COMBINATION		WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	d2	BODY	FLANGE ADAPTER	WEIGHT (KGS)
5141-S27-006-125	PSC40xSAF6C-125	149	125	52	6	21	PSC40 x SAF25	SFC6 - 70	1.28
5141-S27-008-125	PSC40xSAF8C-125	149	125	52	8	21	PSC40 x SAF25	SFC8 - 70	1.27
5141-S27-010-125	PSC40xSAF10C-125	149	125	52	10	24	PSC40 x SAF25	SFC10 - 70	1.32
5141-S27-012-125	PSC40xSAF12C-125	149	125	52	12	24	PSC40 x SAF25	SFC12 - 70	1.30
5141-S27-016-130	PSC40xSAF16C-130	154	130	57	16	27	PSC40 x SAF25	SFC16 - 75	1.35
5142-S27-006-130	PSC50xSAF6C-130	160	130	52	6	21	PSC50 x SAF25	SFC6 - 70	1.62
5142-S27-008-130	PSC50xSAF8C-130	160	130	52	8	21	PSC50 x SAF25	SFC8 - 70	1.61
5142-S27-010-130	PSC50xSAF10C-130	160	130	52	10	24	PSC50 x SAF25	SFC10 - 70	1.66
5142-S27-012-130	PSC50xSAF12C-130	160	130	52	12	24	PSC50 x SAF25	SFC12 - 70	1.64
5142-S27-016-135	PSC50xSAF16C-135	165	135	57	16	27	PSC50 x SAF25	SFC16 - 75	1.69
5143-S27-006-130	PSC63xSAF6C-130	168	130	52	6	21	PSC63 x SAF25	SFC6 - 70	1.97
5143-S27-008-130	PSC63xSAF8C-130	168	130	52	8	21	PSC63 x SAF25	SFC8 - 70	1.96
5143-S27-010-130	PSC63xSAF10C-130	168	130	52	10	24	PSC63 x SAF25	SFC10 - 70	2.01
5143-S27-012-130	PSC63xSAF12C-130	168	130	52	12	24	PSC63 x SAF25	SFC12 - 70	1.99
5143-S27-016-135	PSC63xSAF16C-135	173	135	57	16	27	PSC63 x SAF25	SFC16 - 75	2.04
5143-S27-020-140	PSC63xSAF20C-140	178	140	60	20	33	PSC63 x SAF40	SFC20 - 80	3.01
5143-S27-025-160	PSC63xSAF25C-160	198	160	81	25	44	PSC63 x SAF40	SFC25 - 100	3.54
5143-S27-032-160	PSC63xSAF32C-160	198	160	81	32	44	PSC63 x SAF40	SFC32 - 100	3.40
5144-S27-006-120	PSC80xSAF6C-120	168	120	52	6	21	PSC80 x SAF25	SFC6 - 70	2.55
5144-S27-008-120	PSC80xSAF8C-120	168	120	52	8	21	PSC80 x SAF25	SFC8 - 70	2.54
5144-S27-010-120	PSC80xSAF10C-120	168	120	52	10	24	PSC80 x SAF25	SFC10 - 70	2.59
5144-S27-012-120	PSC80xSAF12C-120	168	120	52	12	24	PSC80 x SAF25	SFC12 - 70	2.57
5144-S27-016-125	PSC80xSAF16C-125	173	125	57	16	27	PSC80 x SAF25	SFC16 - 75	2.62
5144-S27-020-140	PSC80xSAF20C-140	188	140	60	20	33	PSC80 x SAF40	SFC20 - 80	3.81
5144-S27-025-160	PSC80xSAF25C-160	208	160	81	25	44	PSC80 x SAF40	SFC25 - 100	4.34
5144-S27-032-160	PSC80xSAF32C-160	208	160	81	32	44	PSC80 x SAF40	SFC32 - 100	4.20

PSC/SAF可調式刀桿 (SK3)

proimages/Products/Tool_holders/SAF/PSC-SAF-SK3_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5141-S28-006-105	PSC40xSAK6K-105	129	105	29	19.5	PSC40 x SAF25	SK306 - 50	SKS6	1.15
5141-S28-006-155	PSC40xSAF6K-155	179	155	79	19.5	PSC40 x SAF25	SK306 - 100	SKS6	1.24
5141-S28-010-105	PSC40xSAF10K-105	129	105	32.5	27.5	PSC40 x SAF25	SK310 - 50	SKS10	1.18
5141-S28-010-155	PSC40xSAF10K-155	179	155	82.5	27.5	PSC40 x SAF25	SK310 - 100	SKS10	1.37
5141-S28-013-125	PSC40xSAF13K-125	149	125	53	33	PSC40 x SAF25	SK313 - 70	SKS13	1.31
5141-S28-013-155	PSC40xSAF13K-155	179	155	83	33	PSC40 x SAF25	SK313 - 100	SKS13	1.49
5142-S28-006-110	PSC50xSAF6K-110	140	110	29	19.5	PSC50 x SAF25	SK306 - 50	SKS6	1.49
5142-S28-006-160	PSC50xSAF6K-160	190	160	79	19.5	PSC50 x SAF25	SK306 - 100	SKS6	1.58
5142-S28-010-110	PSC50xSAF10K-110	140	110	32.5	27.5	PSC50 x SAF25	SK310 - 50	SKS10	1.52
5142-S28-010-160	PSC50xSAF10K-160	190	160	82.5	27.5	PSC50 x SAF25	SK310 - 100	SKS10	1.71
5142-S28-013-130	PSC50xSAF13K-130	160	130	53	33	PSC50 x SAF25	SK313 - 70	SKS13	1.65
5142-S28-013-160	PSC50xSAF13K-160	190	160	83	33	PSC50 x SAF25	SK313 - 100	SKS13	1.83
5143-S28-006-110	PSC63xSAF6K-110	148	110	29	19.5	PSC63 x SAF25	SK306 - 50	SKS6	1.84
5143-S28-006-160	PSC63xSAF6K-160	198	160	79	19.5	PSC63 x SAF25	SK306 - 100	SKS6	1.93
5143-S28-010-110	PSC63xSAF10K-110	148	110	32.5	27.5	PSC63 x SAF25	SK310 - 50	SKS10	1.87
5143-S28-010-160	PSC63xSAF10K-160	198	160	82.5	27.5	PSC63 x SAF25	SK310 - 100	SKS10	2.06
5143-S28-013-130	PSC63xSAF13K-130	168	130	53	33	PSC63 x SAF25	SK313 - 70	SKS13	2.00
5143-S28-013-160	PSC63xSAF13K-160	198	160	83	33	PSC63 x SAF25	SK313 - 100	SKS13	2.18
5143-S28-016-130	PSC63xSAF16K-130	168	130	49.9	40	PSC63 x SAF40	SK316 - 70	SKS16	2.90
5143-S28-016-160	PSC63xSAF16K-160	198	160	79.9	40	PSC63 x SAF40	SK316 - 100	SKS16	3.16
5144-S28-006-100	PSC80xSAF6K-100	148	100	29	19.5	PSC80 x SAF25	SK306 - 50	SKS6	2.42
5144-S28-006-150	PSC80xSAF6K-150	198	150	79	19.5	PSC80 x SAF25	SK306 - 100	SKS6	2.51
5144-S28-010-100	PSC80xSAF10K-100	148	100	32.5	27.5	PSC80 x SAF25	SK310 - 50	SKS10	2.45
5144-S28-010-150	PSC80xSAF10K-150	198	150	82.5	27.5	PSC80 x SAF25	SK310 - 100	SKS10	2.64
5144-S28-013-120	PSC80xSAF13K-120	168	120	53	33	PSC80 x SAF25	SK313 - 70	SKS13	2.58
5144-S28-013-150	PSC80xSAF13K-150	198	150	83	33	PSC80 x SAF25	SK313 - 100	SKS13	2.76
5144-S28-016-130	PSC80xSAF16K-130	178	130	49.9	40	PSC80 x SAF40	SK316 - 70	SKS16	3.70
5144-S28-016-160	PSC80xSAF16K-160	208	160	79.9	40	PSC80 x SAF40	SK316 - 100	SKS16	3.96

PSC/SAF可調式刀桿 (UT)

proimages/Products/Tool_holders/SAF/PSC-SAF-UT_figure.jpg

MODEL NO.	TYPE	L	l1	l2	d1	COMBINATION		COLLET	WEIGHT (KGS)
MODEL NO.	TYPE	L	l1	l2	d1	BODY	FLANGE ADAPTER	COLLET	WEIGHT (KGS)
5141-S30-016-105	PSC40xSAF16U-105	129	105	32	30	PSC40 x SAF25	UT16 - 50	ER16	1.23
5141-S30-020-105	PSC40xSAF20U-105	129	105	33	35	PSC40 x SAF25	UT20 - 50	ER20	1.25
5142-S30-016-110	PSC50xSAF16U-110	140	110	32	30	PSC50 x SAF25	UT16 - 50	ER16	1.57
5142-S30-020-110	PSC50xSAF20U-110	140	110	33	35	PSC50 x SAF25	UT20 - 50	ER20	1.59
5143-S30-016-110	PSC63xSAF16U-110	148	110	32	30	PSC63 x SAF25	UT16 - 50	ER16	1.92
5143-S30-020-110	PSC63xSAF20U-110	148	110	33	35	PSC63 x SAF25	UT20 - 50	ER20	1.94
5143-S30-025-120	PSC63xSAF25U-120	158	120	38.9	42	PSC63 x SAF40	UT25 - 60	ER25	2.91
5143-S30-032-120	PSC63xSAF32U-120	158	120	40.9	48	PSC63 x SAF40	UT32 - 60	ER32	2.94
5144-S30-016-100	PSC80xSAF16U-100	148	100	32	30	PSC80 x SAF25	UT16 - 50	ER16	2.50
5144-S30-020-100	PSC80xSAF20U-100	148	100	33	35	PSC80 x SAF25	UT20 - 50	ER20	2.52
5144-S30-025-120	PSC80xSAF25U-120	168	120	38.9	42	PSC80 x SAF40	UT25 - 60	ER25	3.71
5144-S30-032-120	PSC80xSAF32U-120	168	120	40.9	48	PSC80 x SAF40	UT32 - 60	ER32	3.74

SAF可調式刀桿本體

proimages/Products/Tool_holders/SAF/SAF_body_figure.jpg

MODEL NO.	TYPE	l1	d2	SAF NO.	WEIGHT (KGS)
5010-783-025-040	BT30xSAF25-40	40	60	1	0.61
5011-783-025-050	BT40xSAF25-50	50	60	1	1.34
5011-783-040-050	BT40xSAF40-50	50	80	2	1.48
5012-783-025-060	BT50xSAF25-60	60	60	1	3.82
5012-783-040-060	BT50xSAF40-60	60	80	2	4.07
5031-783-025-050	CAT40xSAF25-50	50	60	1	1.19
5031-783-040-060	CAT40xSAF40-60	60	80	2	1.71
5032-783-025-060	CAT50xSAF25-60	60	60	1	3.46
5032-783-040-060	CAT50xSAF40-60	60	80	2	3.77
5051-783-025-050	DAT40xSAF25-50	50	60	1	1.22
5051-783-040-060	DAT40xSAF40-60	60	80	2	1.73
5052-783-025-060	DAT50xSAF25-60	60	60	1	3.36
5052-783-040-060	DAT50xSAF40-60	60	80	2	3.92
5071-783-025-060	HSK40AxSAF25-60	60	60	1	0.70
5072-783-025-060	HSK50AxSAF25-60	60	60	1	0.82
5073-783-025-060	HSK63AxSAF25-60	60	60	1	1.16
5073-783-040-060	HSK63AxSAF40-60	60	80	2	1.36
5074-783-025-050	HSK80AxSAF25-50	50	60	1	1.47
5074-783-040-060	HSK80AxSAF40-60	60	80	2	1.95
5075-783-025-055	HSK100AxSAF25-55	55	60	1	2.41
5075-783-040-055	HSK100AxSAF40-55	55	80	2	2.73
5141-783-025-055	PSC40xSAF25-55	55	60	1	0.76
5142-783-025-060	PSC50xSAF25-60	60	60	1	1.10
5143-783-025-060	PSC63xSAF25-60	60	60	1	1.45
5143-783-040-060	PSC63xSAF40-60	60	80	2	1.82
5144-783-025-050	PSC80xSAF25-50	50	60	1	2.03
5144-783-040-060	PSC80xSAF40-60	60	80	2	2.62

MODEL NO.	TYPE	l1	d2	SAF NO.	WEIGHT (KGS)
5025-783-025-040	SBT30xSAF25-40	40	60	1	0.61
5026-783-025-050	SBT40xSAF25-50	50	60	1	1.35
5026-783-040-050	SBT40xSAF40-50	50	80	2	1.49
5027-783-025-060	SBT50xSAF25-60	60	60	1	3.86
5027-783-040-060	SBT50xSAF40-60	60	80	2	4.11
5043-783-025-050	SCAT40xSAF25-50	50	60	1	1.22
5043-783-040-060	SCAT40xSAF40-60	60	80	2	1.73
5044-783-025-060	SCAT50xSAF25-60	60	60	1	3.50
5044-783-040-060	SCAT50xSAF40-60	60	80	2	3.81
5066-783-025-050	SDAT40xSAF25-50	50	60	1	1.24
5066-783-040-060	SDAT40xSAF40-60	60	80	2	1.75
5067-783-025-060	SDAT50xSAF25-60	60	60	1	3.40
5067-783-040-060	SDAT50xSAF40-60	60	80	2	3.96

SAF可調式刀桿法蘭盤 - SFC

proimages/Products/Tool_holders/SAF/SAF-SFC_flange_figure.jpg

MODEL NO.	TYPE	l1	l2	l3	d1	d2	d3	d4	T	SAF NO.	WEIGHT (KGS)
5296-16-006-02-00	SFC6-70	70	36	52	6	21	27	60	M5 x 0.8P	1	0.52
5296-16-008-02-00	SFC8-70	70	36	52	8	21	27	60	M6 x 1.0P	1	0.51
5296-16-010-02-00	SFC10-70	70	42	52	10	24	32	60	M8 x 1.25P	1	0.56
5296-16-012-02-00	SFC12-70	70	47	52	12	24	32	60	M10 x 1.5P	1	0.54
5296-16-016-02-00	SFC16-75	75	50	57	16	27	34	60	M12 x 1.75P	1	0.59
5296-16-020-02-00	SFC20-80	80	52	60	20	33	42	80	M16 x 2.0P	2	1.19
5296-16-025-02-00	SFC25-100	100	58	81	25	44	52	80	M20 x 2.0P	2	1.72
5296-16-032-02-00	SFC32-100	100	58	81	32	44	52	80	M20 x 2.0P	2	1.58

SAF可調式刀桿法蘭盤 - SK3

proimages/Products/Tool_holders/SAF/SAF-SK3_flange_figure.jpg

MODEL NO.	TYPE	l1	l2	d1	d2	d3	SAF NO.	WEIGHT (KGS)
5296-17-006-02-00	SK306-50	50	29	19.5	19.5	60	1	0.39
5296-17-006-02-01	SK306-100	100	79	19.5	19.5	60	1	0.48
5296-17-010-02-00	SK310-50	50	32.5	27.5	27.5	60	1	0.42
5296-17-010-02-01	SK310-100	100	82.5	27.5	27.5	60	1	0.61
5296-17-013-02-00	SK313-70	70	53	33	33	60	1	0.55
5296-17-013-02-01	SK313-100	100	83	33	33	60	1	0.73
5296-17-016-02-00	SK316-70	70	49.9	40	40	80	2	1.08
5296-17-016-02-01	SK316-100	100	79.9	40	40	80	2	1.34

SAF可調式刀桿法蘭盤 - UT

proimages/Products/Tool_holders/SAF/SAF-UT_flange-figure.jpg

MODEL NO.	TYPE	l1	l2	d1	d2	d3	SAF NO.	WEIGHT (KGS)
5296-19-016-02-00	UT16-50	50	32	30	30	60	1	0.47
5296-19-020-02-00	UT20-50	50	33	35	36	60	1	0.49
5296-19-025-02-00	UT25-60	60	38.9	42	42	80	2	1.09
5296-19-032-02-00	UT32-60	60	40.9	48	48	80	2	1.12

series

proimages/New-Product/SAF_Runout_Adjustable_Holder-zh-cover..jpg

series

SAF可調式刀桿組裝應用

SAF可調式刀桿加工應用

SAF可調式刀桿

產品描述
